Frequency

Mid‑Band 5 GHz (5470 - 5950 MHz)

Throughput

1.2+ Gbps

Range

100+ km

Dimension

938.4 x 468.4 x 281.4 mm

Max Power Consumption

40 W

Power Supply

50V, 1.2A PoE GigE Adapter (Included) Passive Power over Ethernet

Mounting

Pole Mount Kit (Included)

Wind Survivability

200 km/hr

Interface

Data Port (1) 10/100/1000 Ethernet Port Config Port (1) 10/100 Ethernet Port Aux Port (1) RJ-12, Alignment Tone Port

Modulation Rates

Up to 1024QAM

Radio Frame Synchronization

GPS Clock Synchronization

Antena

Integrated Split Antenna TX Gain 23 dBi RX Gain 23 dBi

EIRP

(~50 dBm)

Beamwidth

6°

Front-to-Back Ratio

70 dB

Polarity

Dual-Slant Polarization

Compatible Antenas

NA

Applications

PTP

Requires 2 units for a single link.
